Features and Benefits
Technical Data
|
Property |
Test method |
Standard Performance |
Typical Performance |
|
Tensile strength(MPa) |
ASTM D 2671 |
≥12 |
12.5 |
|
Elongation(%) |
ASTM D 2671 |
≥300 |
450 |
|
Tensile strength after aging(MPa) |
MIL-DTL-23053/4 |
≥8.4 |
8.5 |
|
Elongation after aging (%) |
MIL-DTL-23053/4 |
≥100 |
350 |
|
Dielectric strength(kV/mm) |
IEC 60243 |
≥15 |
17.5 |
|
Volume resistivity(Ω.cm) |
IEC 60093 |
≥1*1014 |
2.5*1014 |
Adhesive
|
Property |
Test method |
Standard |
|
Water Absorption |
ASTM D 570 |
≤0.2% |
|
Softening Point(℃) |
ASTM E 28 |
90±5℃ |
|
Strength of pearing (PE) |
ASTMD 1000 |
120N/25mm |
|
Strength of pearing (AL) |
ASTMD 1000 |
80N/25mm |
Dimensions SBRS-(3X)GF
| Size | Expanded |
After Recovery Standard Package |
Standard Package | |||
| Inch | mm | Internal Diameter (mm) | Internal Diameter (mm) | Total Wall Thickness (mm) | Adhesive Thickness (mm) | Spool Length M/spool |
| 1/8 | 3.2 | 3.2 | 1 | 0.90±0.30 | 0.40±0.20 | 200 |
| 3/16 | 4.8 | 4.8 | 1.6 | 1.05±0.30 | 0.40±0.20 | 100 |
| 1/4 | 6.4 | 6.4 | 2.2 | 1.25±0.30 | 0.45±0.20 | 100 |
| 5/16 | 7.9 | 7.9 | 2.7 | 1.35±0.30 | 0.45±0.20 | 100 |
| 3/8 | 9.5 | 9.5 | 3.2 | 1.45±0.30 | 0.50±0.20 | 50 |
| 1/2 | 12.7 | 12.7 | 4.2 | 1.65±0.30 | 0.50±0.20 | 1.22 OR 25M/Roll |
| 5/8 | 15 | 15 | 5.2 | 1.80±0.30 | 0.55±0.30 | 1.22 OR 25M/Roll |
| 3/4 | 19.1 | 19.1 | 6.3 | 1.95±0.30 | 0.60±0.30 | 1.22 OR 25M/Roll |
| 1 | 25.4 | 25.4 | 8.5 | 2.00±0.40 | 0.60±0.30 | 1.22 OR 25M/Roll |
| 1-1/4 | 30 | 30 | 10.2 | 2.15±0.40 | 0.65±0.30 | 1.22 OR 25M/Roll |
| 1-1/2 | 39 | 39 | 13.5 | 2.45±0.40 | 0.75±0.30 | 1.22 OR 25M/Roll |
| 2 | 50 | 50 | 17 | 2.75±0.40 | 0.80±0.30 | 1.22 OR 25M/Roll |
Dimensions SBRS-(4X)GF
| Size | Expanded | After Recovery | Standard Package | |||
| Inch | mm | Internal Diameter (mm) | Internal Diameter (mm) | Total Wall Thickness (mm) | Adhesive Thickness (mm) | Spool Length M/spool |
| 5/32 | 4 | 4 | 1 | 1.05±0.30 | 0.50±0.20 | 200 |
| 1/4 | 6 | 6 | 1.5 | 1.15±0.30 | 0.50±0.20 | 100 |
| 5/16 | 8 | 8 | 2 | 1.55±0.30 | 0.60±0.25 | 50 |
| 1/2 | 12 | 12 | 3 | 1.75±0.30 | 0.60±0.25 | 1.22 OR 25M/Roll |
| 5/8 | 16 | 16 | 4 | 2.00±0.35 | 0.70±0.30 | 1.22 OR 25M/Roll |
| 25/32 | 20 | 20 | 5 | 2.30±0.40 | 0.70±0.30 | 1.22 OR 25M/Roll |
| 1 | 24 | 24 | 6 | 2.60±0.40 | 0.75±0.30 | 1.22 OR 25M/Roll |
| 1-1/4 | 32 | 32 | 8 | 3.00±0.50 | 0.90±0.30 | 1.22 OR 25M/Roll |
| 2 | 52 | 52 | 13 | 3.35±0.50 | 0.95±0.30 | 1.22 OR 25M/Roll |
